Features

  • Compatible with all NZ towball sizes and most configurations (Interchangeable ball systems require 12mm of parallel sided neck under the ball.  Cone shaped ball mounts interfere with the coupler)
  • Easy mounting of bikes through detachable bike arms
  • Carries bikes with large wheelbases thanks to single action extendable wheel holders
  • Wide tilt angle allows opening of even very large rear doors - even with bikes mounted. We recommend test fitting on tall vans to confirm clearance
  • Easy boot access even with bikes mounted thanks to smart foot pedal tilt
  • Adjustable one hand coupling for easy mounting of carrier
  • Simple to fasten wheels thanks to long wheel straps with pump buckles
  • Simple to fold flat and store – fits most car boots
  • Lock your bikes to the bike carrier and your carrier to the tow bar (locks included)
  • Pre-assembled, no tools required
  • Fulfills the City Crash norm
  • Compatible with all towball sizes and most configurations (except 47mm gooseneck / Euro style and interchangeable ball mounts with cone shaped bases)
  • Fitted with NZ flat 7 pin trailer wiring plug

Technical Specifications

Load capacity Bikes
 2
Load capacity (kg)

46 kg - Reduce capacity by 10kg when installed on camper, bus, motorhome or truck, or when used off-road

Fits wheel dimensions

3" Max

Max bike weight

25 kg

Distance between bikes

19 cm

Length (cm)

103 cm

Width (cm)

59 cm

Weight (kg)

14.3 kg

Fits frame dimensions

22-80 mm

Detachable frame holders

 √

Tiltable with bikes

 √

One Key System compatible

 √

Fits cars with exterior spare tyre

 Adapter Required: Thule VeloCompact Spare wheel adapter

Fits most bikes with disc brakes

 √

Rear lights

 √

Powerplug

7-pin

TÜV Approved

-

Fulfils City Crash norm

 √

Miscellaneous

-

SKU No

924003

Resources

Important documents for your Thule product

View Fitting Instructions Spare Parts
